Products
Research-grade logging accelerometers and the accessories that go with them. Prices exclude VAT.
Logging sensors
AX33-axis logging accelerometer
A data logger with a MEMS 3-axis accelerometer, flash on-board memory, real-time quartz clock and temperature sensor. Built for longitudinal movement data.
- Accelerometer Sample Rate
- 12.5 - 3200Hz configurable
- Battery Life
- 30 days @ 12.5Hz; 14 days @ 100Hz
- Accelerometer Range
- ±2 / 4 / 8 / 16g configurable
- Memory
- 512mb flash non-volatile
£139.00–£149.00 exc VAT
AX66-axis logging accelerometer
Records raw data from a 6-axis movement sensor measuring linear acceleration and angular velocity. Sensor placement matches the AX3 for compatibility.
- Accelerometer Sample Rate
- 12.5 - 1600Hz configurable
- Battery Life
- 7+ days @ 100Hz, Accel & Gyro 31+ days @ 50Hz, Accel only
- Accelerometer Range
- ±2 / 4 / 8 / 16g configurable
- Memory
- 1024mb flash non-volatile
£199.00–£209.00 exc VAT
Accessories
Compare AX3 and AX6
Every value as Axivity publishes it. A dash means Axivity gives no figure for that device.
| Specification | AX3 | AX6 |
|---|---|---|
| Physical Parameters | ||
| Dimensions | 23 x 32.5 x 7.6 (mm) | 23 x 32.5 x 8.9 (mm) |
| Weight | 11g | 11g |
| Environmental Protection | ||
| Moisture Ingress | IPx8 1.5m for 1 hour | IPx8 1.5m for 1 hour |
| Dust Ingress | IP6x | IP6x |
| Typical Capabilities | ||
| Memory | 512mb flash non-volatile | 1024mb flash non-volatile |
| Accelerometer Sample Rate | 12.5 - 3200Hz configurable | 12.5 - 1600Hz configurable |
| Battery Life | 30 days @ 12.5Hz; 14 days @ 100Hz | 7+ days @ 100Hz, Accel & Gyro 31+ days @ 50Hz, Accel only |
| Accelerometer Range | ±2 / 4 / 8 / 16g configurable | ±2 / 4 / 8 / 16g configurable |
| Accelerometer Resolution | Up-to 13 bit | Not stated |
| Gyroscope Range | Not stated | ±125 / 250 / 500 / 1000 / 2000 dps configurable |
| Sensor Resolution | Not stated | 16 bit, Accel and Gyro |
